Mexco TPXCEL 450mm Tri Purpose Diamond Blade
Order in next:
Summary
- Best in class 450mm diamond blade
- Designed for cutting the widest variety of materials
- Suitable for abrasive, non abrasive and asphalt
- 25.4mm bore size
- 3.6mm segment width
- Castellated segment for quick stock clearance
- Ventilation cooling holes for rapid heat dispersion
- TCT undercutting protection
- Wet or dry use
- Suitable for disc cutters, angle grinders, bench saws & floor saws
Delivery Options
Specification
SKU: TPXCEL45025
Diameter: 450mm (18 inch)
Segment Height: 10mm
Segment Width: 3.6mm
Bore Size: 25.4mm
Dry / Wet: Can be used wet or dry
Grade: XCEL
Gullet Type: Keyhole
Recommended Tool: Angle Grinder, Bench Saw, Disc Cutter, Floor Saw
Segment Attachment: Laser Welded
Segment Type: Segmented
Undercutting Protection: Yes
Ventilation: Yes
Brand: | Mexco |
---|---|
Range: | XCEL |
Applications: | Multi-Use |
Diameter (mm): | 450 |
Bore Size (mm): | 25.40 |
Materials: | Soft Slate |
Materials: | Medium Sandstone |
Materials: | Concrete Roof Tiles |
Materials: | Concrete with Med Sharp Sand |
Materials: | Coarse Sandstone |
Materials: | Breeze Block |
Materials: | Concrete Paviours |
Materials: | Soft Facing Brick |
Materials: | Concrete Blocks Over 15KN |
Materials: | Hard Sandstone |
Materials: | Shallow Concrete Screed |
Materials: | Asphalt Over Concrete |
Materials: | Concrete Blocks Under 15KN |
Materials: | Green Concrete |
Materials: | Medium Facing Brick |
Materials: | Hard Slate |
Materials: | River Gravel Aggregate Concrete |
Materials: | Flint Aggregate Concrete |
Materials: | Reinforced Concrete |
Materials: | Concrete Kerbs |
Materials: | Concrete Slabs |
Materials: | Reinforced Lintels |
Materials: | Hard Limestone |
Materials: | Limestone Aggregate Concrete |
Materials: | Hard Facing Brick |
Materials: | Lignacite Blocks |
Materials: | Asphalt |
Materials: | Ductile Iron |
Materials: | Granite |
Materials: | Class A Engineering Brick |
Materials: | Clay Paviours |
Materials: | Clay Pipes Vitrified |
Materials: | Clay Roof Tiles |
Materials: | Quarry Tiles |
Materials: | Non Abrasive Indian Sandstone |
Suitable Tool: | Disc Cutter |
Suitable Tool: | Bench Saw |
Suitable Tool: | Angle Grinder |
Suitable Tool: | Floor Saw |
0 Reviews
There are currently no reviews for this product
Write a review
Mexco TPXCEL 450mm Tri Purpose Diamond Blade
Superior cutting of all general purpose construction materials
The Mexco TPXCEL Tri-purpose diamond blade is designed for cutting all general purpose building and construction materials, including abrasive, non abrasive and asphalt materials.
This 450mm blade features a 25.4mm bore size. It can be used in a disc cutter, angle grinder, bench saw & floor saw, and for wet or dry use.
Designed specifically to take away the hassle of having to change diamond blades for different materials, this blade can be used to cut materials such as reinforced concrete, concrete block, asphalt, ductile iron, granite, engineering brick, limestone and breeze blocks.
The Mexco TPXCEL Tri-purpose disc blade has been developed using the most advanced manufacturing techniques. TCT undercutting protection ensures the segments are protected against undercutting (which renders the blade not only useless but dangerous). The steel centre has ventilation holes for cooling and the segments have been laser welded.
This blade provides you with the ideal tool for the most common cutting applications, already mounted on your saw.
About the Mexco XCEL Grade of Diamond Blades
The XCEL range of products are simply the best in class, due to an uncompromised use of raw materials in their manufacture. They offer the user a diamond cutting or drilling experience that is faster and cleaner resulting in an optimum cost per cut. These blades have been developed to meet the needs of contractors and builders who cut on a regular basis and demand a superior cut every time.
Applications
- Medium Facing Brick
- Hard Slate
- River Gravel Aggregate Concrete
- Flint Aggregate Concrete
- Reinforced Concrete
- Concrete Kerbs
- Concrete Slabs
- Reinforced Lintels
- Hard Limestone
- Limestone Aggregate Concrete
- Concrete Paviours
- Soft Facing Brick
- Concrete Blocks Over 15KN
- Hard Sandstone
- Soft Slate
- Medium Sandstone
- Concrete Roof Tiles
- Concrete with Med Sharp Sand
- Coarse Sandstone
- Breeze Block
- Shallow Concrete Screed
- Asphalt Over Concrete
- Concrete Blocks Under 15KN *
- Green Concrete *
- Lignacite Blocks *
- Asphalt *
- Ductile Iron *
- Granite *
- Class A Engineering Brick *
- Clay Paviours *
- Clay Pipes Vitrified *
- Clay Roof Tiles *
- Quarry Tiles *
- Non Abrasive Indian Sandstone *
- Hard Facing Brick *
* Will cut these materials but may result in reduced lifetime or glazing
